플래시 액션스크립트 오각형 그리기 능력치 업무도 표시를 위한 다이어그램 관련 (업무 그래프, 위닝 능력치)









=================================

=================================

=================================













출처: (여기)  202psj.tistory.com



통째로 구현 코드.



package

{

import flash.display.InteractiveObject;

import flash.display.LoaderInfo;

import flash.display.Sprite;

import flash.display.StageAlign;

import flash.display.StageScaleMode;

import flash.events.Event;

import flash.geom.Point;

import flash.text.TextField;

import flashx.textLayout.formats.Float;



[SWF(width=305, height=283, backgroundColor=0xffffff)]

//[SWF(backgroundColor=0x000000)]



public class testPentagon extends Sprite

{

//팬타곤 그래프 이미지 크기

public static var _SCREEN_W:int = 305;

public static var _SCREEN_H:int = 283;



public var _chartBG:RImgPentagon = new RImgPentagon(); //배경 이미지 스프라이트 클래스 (swc에서가져옴)

public var _pentagon:Sprite = new Sprite();



public static var _me:testPentagon = null;

public const point1:Point = new Point(153, 32);

public const point2:Point = new Point(260, 110);

public const point3:Point = new Point(220, 235);

public const point4:Point = new Point(87, 235);

public const point5:Point = new Point(46, 110);



public var point1tmp:Point = new Point(point1.x, point1.y);

public var point2tmp:Point = new Point(point2.x, point2.y);

public var point3tmp:Point = new Point(point3.x, point3.y);

public var point4tmp:Point = new Point(point4.x, point4.y);

public var point5tmp:Point = new Point(point5.x, point5.y);



public const pointCenter:Point = new Point(154, 145);



public var _max:int    = 5;

public var _point1:int = 5;

public var _point2:int = 5;

public var _point3:int = 5;

public var _point4:int = 5;

public var _point5:int = 5;





public function testPentagon()

{

_me = this;



addChild(_chartBG);



stage.scaleMode = StageScaleMode.NO_SCALE;

stage.align = StageAlign.TOP_LEFT;

_ParameterStr = getParameters(this.root.loaderInfo);



//test

setPoint1Val(3);

setPoint2Val(3);

setPoint3Val(3);

setPoint4Val(3);

setPoint5Val(4);



drawPentagon();

}



public function setMax(val:int):void

{

_max = val;

}



public function setPoint1Val(val:int):void

{

_point1 = val;



var per:Number = Number(val/_max);

var tmp:Number = pointCenter.y - point1.y;

tmp = tmp * per;

point1tmp.y = pointCenter.y - tmp;

}



public function setPoint2Val(val:int):void

{

_point2 = val;



//각각 x,y 의 길이  106, 35 길이대비 3:1

var per:Number = Number(val/_max);

var wid:Number = point2.x - pointCenter.x;

var hei:Number = pointCenter.y - point2.y;

var sc:Number = hei/wid; //길이대비

var wPer:Number = wid * per; //퍼센트 비율 가로길이

var pW:Number = pointCenter.x+(wPer);

var pH:Number = pointCenter.y-(wPer * sc);

point2tmp.x = pW;

point2tmp.y = pH;

}



public function setPoint3Val(val:int):void

{

_point3 = val;



var per:Number = Number(val/_max);

var wid:Number = point3.x - pointCenter.x;

var hei:Number = pointCenter.y - point3.y;

var sc:Number = hei/wid; //길이대비

var wPer:Number = wid * per; //퍼센트 비율 가로길이

var pW:Number = pointCenter.x+(wPer);

var pH:Number = pointCenter.y-(wPer * sc);

point3tmp.x = pW;

point3tmp.y = pH;



}



public function setPoint4Val(val:int):void

{

_point4 = val;



var per:Number = Number(val/_max);

var wid:Number = point4.x - pointCenter.x;

var hei:Number = pointCenter.y - point4.y;

var sc:Number = hei/wid; //길이대비

var wPer:Number = wid * per; //퍼센트 비율 가로길이

var pW:Number = pointCenter.x+(wPer);

var pH:Number = pointCenter.y-(wPer * sc);

point4tmp.x = pW;

point4tmp.y = pH;

}



public function setPoint5Val(val:int):void

{

_point5 = val;



var per:Number = Number(val/_max);

var wid:Number = point5.x - pointCenter.x;

var hei:Number = pointCenter.y - point5.y;

var sc:Number = hei/wid; //길이대비

var wPer:Number = wid * per; //퍼센트 비율 가로길이

var pW:Number = pointCenter.x+(wPer);

var pH:Number = pointCenter.y-(wPer * sc);

point5tmp.x = pW;

point5tmp.y = pH;

}



public function drawPentagon():void

{

//꼭지점 부터 시계 방형 순으로

_pentagon.graphics.beginFill(0x80FF0000, 0.1);

_pentagon.graphics.moveTo(point1tmp.x, point1tmp.y);              //꼭대기  꼭지점1

_pentagon.graphics.lineTo(point2tmp.x, point2tmp.y);              //오른쪽  꼭지점2

_pentagon.graphics.lineTo(pointCenter.x, pointCenter.y);    //꼭센터 꼭지점



_pentagon.graphics.beginFill(0x80FF0000, 0.3);

_pentagon.graphics.moveTo(point2tmp.x, point2tmp.y);              //꼭대기  꼭지점2

_pentagon.graphics.lineTo(point3tmp.x, point3tmp.y);              //오른쪽  꼭지점3

_pentagon.graphics.lineTo(pointCenter.x, pointCenter.y);    //센터 꼭지점



_pentagon.graphics.beginFill(0x80FF0000, 0.4);

_pentagon.graphics.moveTo(point3tmp.x, point3tmp.y);              //꼭대기  꼭지점3

_pentagon.graphics.lineTo(point4tmp.x, point4tmp.y);              //오른쪽  꼭지점4

_pentagon.graphics.lineTo(pointCenter.x, pointCenter.y);    //센터 꼭지점



_pentagon.graphics.beginFill(0x80FF0000, 0.3);

_pentagon.graphics.moveTo(point4tmp.x, point4tmp.y);              //꼭대기  꼭지점4

_pentagon.graphics.lineTo(point5tmp.x, point5tmp.y);              //오른쪽  꼭지점5

_pentagon.graphics.lineTo(pointCenter.x, pointCenter.y);    //센터 꼭지점



_pentagon.graphics.beginFill(0x80FF0000, 0.1);

_pentagon.graphics.moveTo(point5tmp.x, point5tmp.y);              //꼭대기  꼭지점5

_pentagon.graphics.lineTo(point1tmp.x, point1tmp.y);              //오른쪽  꼭지점1

_pentagon.graphics.lineTo(pointCenter.x, pointCenter.y);    //센터 꼭지점



this.addChild(_pentagon);

}



public function destroy():void

{

//삭제....처리..

}

}

}





=================================

=================================

=================================
