출처: http://developer.android.com/reference/android/app/DownloadManager.html



DownloadManager

extends Object
java.lang.Object
   ↳ android.app.DownloadManager

Class Overview


The download manager is a system service that handles long-running HTTP downloads. Clients may request that a URI be downloaded to a particular destination file. The download manager will conduct the download in the background, taking care of HTTP interactions and retrying downloads after failures or across connectivity changes and system reboots. Instances of this class should be obtained through getSystemService(String) by passing DOWNLOAD_SERVICE. Apps that request downloads through this API should register a broadcast receiver for ACTION_NOTIFICATION_CLICKED to appropriately handle when the user clicks on a running download in a notification or from the downloads UI. Note that the application must have the INTERNET permission to use this class.

Summary


Nested Classes
class DownloadManager.Query This class may be used to filter download manager queries.
class DownloadManager.Request This class contains all the information necessary to request a new download.
Constants
String ACTION_DOWNLOAD_COMPLETE Broadcast intent action sent by the download manager when a download completes.
String ACTION_NOTIFICATION_CLICKED Broadcast intent action sent by the download manager when the user clicks on a running download, either from a system notification or from the downloads UI.
String ACTION_VIEW_DOWNLOADS Intent action to launch an activity to display all downloads.
String COLUMN_BYTES_DOWNLOADED_SO_FAR Number of bytes download so far.
String COLUMN_DESCRIPTION The client-supplied description of this download.
String COLUMN_ID An identifier for a particular download, unique across the system.
String COLUMN_LAST_MODIFIED_TIMESTAMP Timestamp when the download was last modified, in System.currentTimeMillis() (wall clock time in UTC).
String COLUMN_LOCAL_FILENAME The pathname of the file where the download is stored.
String COLUMN_LOCAL_URI Uri where downloaded file will be stored.
String COLUMN_MEDIAPROVIDER_URI The URI to the corresponding entry in MediaProvider for this downloaded entry.
String COLUMN_MEDIA_TYPE Internet Media Type of the downloaded file.
String COLUMN_REASON Provides more detail on the status of the download.
String COLUMN_STATUS Current status of the download, as one of the STATUS_* constants.
String COLUMN_TITLE The client-supplied title for this download.
String COLUMN_TOTAL_SIZE_BYTES Total size of the download in bytes.
String COLUMN_URI URI to be downloaded.
int ERROR_CANNOT_RESUME Value of COLUMN_REASON when some possibly transient error occurred but we can't resume the download.
int ERROR_DEVICE_NOT_FOUND Value of COLUMN_REASON when no external storage device was found.
int ERROR_FILE_ALREADY_EXISTS Value of COLUMN_REASON when the requested destination file already exists (the download manager will not overwrite an existing file).
int ERROR_FILE_ERROR Value of COLUMN_REASON when a storage issue arises which doesn't fit under any other error code.
int ERROR_HTTP_DATA_ERROR Value of COLUMN_REASON when an error receiving or processing data occurred at the HTTP level.
int ERROR_INSUFFICIENT_SPACE Value of COLUMN_REASON when there was insufficient storage space.
int ERROR_TOO_MANY_REDIRECTS Value of COLUMN_REASON when there were too many redirects.
int ERROR_UNHANDLED_HTTP_CODE Value of COLUMN_REASON when an HTTP code was received that download manager can't handle.
int ERROR_UNKNOWN Value of COLUMN_ERROR_CODE when the download has completed with an error that doesn't fit under any other error code.
String EXTRA_DOWNLOAD_ID Intent extra included with ACTION_DOWNLOAD_COMPLETE intents, indicating the ID (as a long) of the download that just completed.
String EXTRA_NOTIFICATION_CLICK_DOWNLOAD_IDS When clicks on multiple notifications are received, the following provides an array of download ids corresponding to the download notification that was clicked.
String INTENT_EXTRAS_SORT_BY_SIZE Intent extra included with ACTION_VIEW_DOWNLOADS to start DownloadApp in sort-by-size mode.
int PAUSED_QUEUED_FOR_WIFI Value of COLUMN_REASON when the download exceeds a size limit for downloads over the mobile network and the download manager is waiting for a Wi-Fi connection to proceed.
int PAUSED_UNKNOWN Value of COLUMN_REASON when the download is paused for some other reason.
int PAUSED_WAITING_FOR_NETWORK Value of COLUMN_REASON when the download is waiting for network connectivity to proceed.
int PAUSED_WAITING_TO_RETRY Value of COLUMN_REASON when the download is paused because some network error occurred and the download manager is waiting before retrying the request.
int STATUS_FAILED Value of COLUMN_STATUS when the download has failed (and will not be retried).
int STATUS_PAUSED Value of COLUMN_STATUS when the download is waiting to retry or resume.
int STATUS_PENDING Value of COLUMN_STATUS when the download is waiting to start.
int STATUS_RUNNING Value of COLUMN_STATUS when the download is currently running.
int STATUS_SUCCESSFUL Value of COLUMN_STATUS when the download has successfully completed.
Public Methods
long addCompletedDownload(String title, String description, boolean isMediaScannerScannable, String mimeType, String path, long length, boolean showNotification)
Adds a file to the downloads database system, so it could appear in Downloads App (and thus become eligible for management by the Downloads App).
long enqueue(DownloadManager.Request request)
Enqueue a new download.
static Long getMaxBytesOverMobile(Context context)
Returns maximum size, in bytes, of downloads that may go over a mobile connection; or null if there's no limit
String getMimeTypeForDownloadedFile(long id)
Returns the media type of the given downloaded file id, if the file was downloaded successfully.
static Long getRecommendedMaxBytesOverMobile(Context context)
Returns recommended maximum size, in bytes, of downloads that may go over a mobile connection; or null if there's no recommended limit.
Uri getUriForDownloadedFile(long id)
Returns the Uri of the given downloaded file id, if the file is downloaded successfully.
ParcelFileDescriptor openDownloadedFile(long id)
Open a downloaded file for reading.
Cursor query(DownloadManager.Query query)
Query the download manager about downloads that have been requested.
int remove(long... ids)
Cancel downloads and remove them from the download manager.
[Expand]
Inherited Methods
From class java.lang.Object

Constants


public static final String ACTION_DOWNLOAD_COMPLETE

Added in API level 9

Broadcast intent action sent by the download manager when a download completes.

Constant Value: "android.intent.action.DOWNLOAD_COMPLETE"

public static final String ACTION_NOTIFICATION_CLICKED

Added in API level 9

Broadcast intent action sent by the download manager when the user clicks on a running download, either from a system notification or from the downloads UI.

Constant Value: "android.intent.action.DOWNLOAD_NOTIFICATION_CLICKED"

public static final String ACTION_VIEW_DOWNLOADS

Added in API level 9

Intent action to launch an activity to display all downloads.

Constant Value: "android.intent.action.VIEW_DOWNLOADS"

public static final String COLUMN_BYTES_DOWNLOADED_SO_FAR

Added in API level 9

Number of bytes download so far.

Constant Value: "bytes_so_far"

public static final String COLUMN_DESCRIPTION

Added in API level 9

The client-supplied description of this download. This will be displayed in system notifications. Defaults to the empty string.

Constant Value: "description"

public static final String COLUMN_ID

Added in API level 9

An identifier for a particular download, unique across the system. Clients use this ID to make subsequent calls related to the download.

Constant Value: "_id"

public static final String COLUMN_LAST_MODIFIED_TIMESTAMP

Added in API level 9

Timestamp when the download was last modified, in System.currentTimeMillis() (wall clock time in UTC).

Constant Value: "last_modified_timestamp"

public static final String COLUMN_LOCAL_FILENAME

Added in API level 11

The pathname of the file where the download is stored.

Constant Value: "local_filename"

public static final String COLUMN_LOCAL_URI

Added in API level 9

Uri where downloaded file will be stored. If a destination is supplied by client, that URI will be used here. Otherwise, the value will initially be null and will be filled in with a generated URI once the download has started.

Constant Value: "local_uri"

public static final String COLUMN_MEDIAPROVIDER_URI

Added in API level 9

The URI to the corresponding entry in MediaProvider for this downloaded entry. It is used to delete the entries from MediaProvider database when it is deleted from the downloaded list.

Constant Value: "mediaprovider_uri"

public static final String COLUMN_MEDIA_TYPE

Added in API level 9

Internet Media Type of the downloaded file. If no value is provided upon creation, this will initially be null and will be filled in based on the server's response once the download has started.

Constant Value: "media_type"

public static final String COLUMN_REASON

Added in API level 9

Provides more detail on the status of the download. Its meaning depends on the value of COLUMN_STATUS. When COLUMN_STATUS is STATUS_FAILED, this indicates the type of error that occurred. If an HTTP error occurred, this will hold the HTTP status code as defined in RFC 2616. Otherwise, it will hold one of the ERROR_* constants. When COLUMN_STATUS is STATUS_PAUSED, this indicates why the download is paused. It will hold one of the PAUSED_* constants. If COLUMN_STATUS is neither STATUS_FAILED nor STATUS_PAUSED, this column's value is undefined.

Constant Value: "reason"

public static final String COLUMN_STATUS

Added in API level 9

Current status of the download, as one of the STATUS_* constants.

Constant Value: "status"

public static final String COLUMN_TITLE

Added in API level 9

The client-supplied title for this download. This will be displayed in system notifications. Defaults to the empty string.

Constant Value: "title"

public static final String COLUMN_TOTAL_SIZE_BYTES

Added in API level 9

Total size of the download in bytes. This will initially be -1 and will be filled in once the download starts.

Constant Value: "total_size"

public static final String COLUMN_URI

Added in API level 9

URI to be downloaded.

Constant Value: "uri"

public static final int ERROR_CANNOT_RESUME

Added in API level 9

Value of COLUMN_REASON when some possibly transient error occurred but we can't resume the download.

Constant Value: 1008 (0x000003f0)

public static final int ERROR_DEVICE_NOT_FOUND

Added in API level 9

Value of COLUMN_REASON when no external storage device was found. Typically, this is because the SD card is not mounted.

Constant Value: 1007 (0x000003ef)

public static final int ERROR_FILE_ALREADY_EXISTS

Added in API level 9

Value of COLUMN_REASON when the requested destination file already exists (the download manager will not overwrite an existing file).

Constant Value: 1009 (0x000003f1)

public static final int ERROR_FILE_ERROR

Added in API level 9

Value of COLUMN_REASON when a storage issue arises which doesn't fit under any other error code. Use the more specific ERROR_INSUFFICIENT_SPACE and ERROR_DEVICE_NOT_FOUND when appropriate.

Constant Value: 1001 (0x000003e9)

public static final int ERROR_HTTP_DATA_ERROR

Added in API level 9

Value of COLUMN_REASON when an error receiving or processing data occurred at the HTTP level.

Constant Value: 1004 (0x000003ec)

public static final int ERROR_INSUFFICIENT_SPACE

Added in API level 9

Value of COLUMN_REASON when there was insufficient storage space. Typically, this is because the SD card is full.

Constant Value: 1006 (0x000003ee)

public static final int ERROR_TOO_MANY_REDIRECTS

Added in API level 9

Value of COLUMN_REASON when there were too many redirects.

Constant Value: 1005 (0x000003ed)

public static final int ERROR_UNHANDLED_HTTP_CODE

Added in API level 9

Value of COLUMN_REASON when an HTTP code was received that download manager can't handle.

Constant Value: 1002 (0x000003ea)

public static final int ERROR_UNKNOWN

Added in API level 9

Value of COLUMN_ERROR_CODE when the download has completed with an error that doesn't fit under any other error code.

Constant Value: 1000 (0x000003e8)

public static final String EXTRA_DOWNLOAD_ID

Added in API level 9

Intent extra included with ACTION_DOWNLOAD_COMPLETE intents, indicating the ID (as a long) of the download that just completed.

Constant Value: "extra_download_id"

public static final String EXTRA_NOTIFICATION_CLICK_DOWNLOAD_IDS

Added in API level 11

When clicks on multiple notifications are received, the following provides an array of download ids corresponding to the download notification that was clicked. It can be retrieved by the receiver of this Intent using getLongArrayExtra(String).

Constant Value: "extra_click_download_ids"

public static final String INTENT_EXTRAS_SORT_BY_SIZE

Added in API level 12

Intent extra included with ACTION_VIEW_DOWNLOADS to start DownloadApp in sort-by-size mode.

Constant Value: "android.app.DownloadManager.extra_sortBySize"

public static final int PAUSED_QUEUED_FOR_WIFI

Added in API level 9

Value of COLUMN_REASON when the download exceeds a size limit for downloads over the mobile network and the download manager is waiting for a Wi-Fi connection to proceed.

Constant Value: 3 (0x00000003)

public static final int PAUSED_UNKNOWN

Added in API level 9

Value of COLUMN_REASON when the download is paused for some other reason.

Constant Value: 4 (0x00000004)

public static final int PAUSED_WAITING_FOR_NETWORK

Added in API level 9

Value of COLUMN_REASON when the download is waiting for network connectivity to proceed.

Constant Value: 2 (0x00000002)

public static final int PAUSED_WAITING_TO_RETRY

Added in API level 9

Value of COLUMN_REASON when the download is paused because some network error occurred and the download manager is waiting before retrying the request.

Constant Value: 1 (0x00000001)

public static final int STATUS_FAILED

Added in API level 9

Value of COLUMN_STATUS when the download has failed (and will not be retried).

Constant Value: 16 (0x00000010)

public static final int STATUS_PAUSED

Added in API level 9

Value of COLUMN_STATUS when the download is waiting to retry or resume.

Constant Value: 4 (0x00000004)

public static final int STATUS_PENDING

Added in API level 9

Value of COLUMN_STATUS when the download is waiting to start.

Constant Value: 1 (0x00000001)

public static final int STATUS_RUNNING

Added in API level 9

Value of COLUMN_STATUS when the download is currently running.

Constant Value: 2 (0x00000002)

public static final int STATUS_SUCCESSFUL

Added in API level 9

Value of COLUMN_STATUS when the download has successfully completed.

Constant Value: 8 (0x00000008)

Public Methods


public long addCompletedDownload (String title, String description, boolean isMediaScannerScannable, String mimeType, String path, long length, boolean showNotification)

Added in API level 12

Adds a file to the downloads database system, so it could appear in Downloads App (and thus become eligible for management by the Downloads App).

It is helpful to make the file scannable by MediaScanner by setting the param isMediaScannerScannable to true. It makes the file visible in media managing applications such as Gallery App, which could be a useful purpose of using this API.

Parameters
title the title that would appear for this file in Downloads App.
description the description that would appear for this file in Downloads App.
isMediaScannerScannable true if the file is to be scanned by MediaScanner. Files scanned by MediaScanner appear in the applications used to view media (for example, Gallery app).
mimeType mimetype of the file.
path absolute pathname to the file. The file should be world-readable, so that it can be managed by the Downloads App and any other app that is used to read it (for example, Gallery app to display the file, if the file contents represent a video/image).
length length of the downloaded file
showNotification true if a notification is to be sent, false otherwise
Returns
  • an ID for the download entry added to the downloads app, unique across the system This ID is used to make future calls related to this download.

public long enqueue (DownloadManager.Request request)

Added in API level 9

Enqueue a new download. The download will start automatically once the download manager is ready to execute it and connectivity is available.

Parameters
request the parameters specifying this download
Returns
  • an ID for the download, unique across the system. This ID is used to make future calls related to this download.

public static Long getMaxBytesOverMobile (Context context)

Added in API level 11

Returns maximum size, in bytes, of downloads that may go over a mobile connection; or null if there's no limit

Parameters
context the Context to use for accessing the ContentResolver
Returns
  • maximum size, in bytes, of downloads that may go over a mobile connection; or null if there's no limit

public String getMimeTypeForDownloadedFile (long id)

Added in API level 11

Returns the media type of the given downloaded file id, if the file was downloaded successfully. Otherwise, null is returned.

Parameters
id the id of the downloaded file.
Returns
  • the media type of the given downloaded file id, if download was successful. null otherwise.

public static Long getRecommendedMaxBytesOverMobile (Context context)

Added in API level 11

Returns recommended maximum size, in bytes, of downloads that may go over a mobile connection; or null if there's no recommended limit. The user will have the option to bypass this limit.

Parameters
context the Context to use for accessing the ContentResolver
Returns
  • recommended maximum size, in bytes, of downloads that may go over a mobile connection; or null if there's no recommended limit.

public Uri getUriForDownloadedFile (long id)

Added in API level 11

Returns the Uri of the given downloaded file id, if the file is downloaded successfully. Otherwise, null is returned.

If the specified downloaded file is in external storage (for example, /sdcard dir), then it is assumed to be safe for anyone to read and the returned Uri corresponds to the filepath on sdcard.

Parameters
id the id of the downloaded file.
Returns
  • the Uri of the given downloaded file id, if download was successful. null otherwise.

public ParcelFileDescriptor openDownloadedFile (long id)

Added in API level 9

Open a downloaded file for reading. The download must have completed.

Parameters
id the ID of the download
Returns
Throws
FileNotFoundException if the destination file does not already exist

public Cursor query (DownloadManager.Query query)

Added in API level 9

Query the download manager about downloads that have been requested.

Parameters
query parameters specifying filters for this query
Returns
  • a Cursor over the result set of downloads, with columns consisting of all the COLUMN_* constants.

public int remove (long... ids)

Added in API level 9

Cancel downloads and remove them from the download manager. Each download will be stopped if it was running, and it will no longer be accessible through the download manager. If there is a downloaded file, partial or complete, it is deleted.

Parameters
ids the IDs of the downloads to remove
Returns
  • the number of downloads actually removed









=================================

=================================

=================================









출처: http://androidhuman.tistory.com/entry/%EB%8D%B0%EC%9D%B4%ED%84%B0-%EB%8B%A4%EC%9A%B4%EB%A1%9C%EB%93%9C%EB%8A%94-%EB%82%B4%EA%B2%8C-DownloadManager-%EC%82%AC%EC%9A%A9%ED%95%98%EA%B8%B0









많은 용량의 데이터를 필요로 하는 애플리케이션 혹은 주기적으로 데이터를 업데이트 할 필요가 있는 애플리케이션들은 인터넷에서 데이터를 직접 다운로드하는 기능을 포함해야 합니다. 하지만, 데이터를 다운로드 하는 기능을 구현하는 것이 그렇게 만만한 작업은 아니였습니다.


UI 쓰레드의 정지를 방지하기 위해 다운로드 작업은 별도 쓰레드에서 구현해야 했으며, 사용자에게 다운로드 현황을 알려주기 위해 ProgressBar 혹은 ProgressDialog를 사용해야 했습니다. 게다가 일부 코드는 애플리케이션 생애주기를 고려하지 않고 작성하여 사용자의 예기치 않은 동작 때문에 오류가 발생하기도 쉬웠습니다.

안드로이드 2.3에서는 이러한 불편을 해소하기 위해 파일 다운로드를 편하게 해주는 DownloadManager 클래스를 제공합니다.

DownloadManager 클래스의 구성

DownloadManager는 크게 다음과 같은 세가지 클래스로 구성되어 있습니다.

  • DownloadManager : 다운로드 시작/취소, 다운로드 파일 열기, 다운로드한 항목 조회 메서드 제공
  • DownloadManager.Request : 다운로드 시작에 필요한 정보 포함
  • DownloadManager.Query : 다운로드 항목 조회에 필요한 정보 포함

DownloadManager

파일 다운로드와 관련된 모든 동작을 담당합니다. DownloadManager 클래스에서 사용 가능한 메서드는 다음과 같습니다.

API
public long enqueue (DownloadManager.Request request)
새로운 다운로드 작업을 요청합니다. 요청한 작업은 다운로드 대기열에 추가됩니다. 다운로드 대기열에 추가된 작업의 ID를 반환합니다.

public int remove (long... ids)
요청한 다운로드 작업을 취소합니다.

public Cursor query (DownloadManager.Query query)
DownloadManager를 통해 다운로드한 항목들 중 조건에 일치하는 항목을 검색합니다. 결과는 Cursor 형태로 반환됩니다. 결과 레코드의 값을 참조하기 위한 필드 값은 DownloadManager.COLUMN_으로 시작하는 상수들(예:DownloadManager.COLUMN_TITLE)을 사용하여 얻을 수 있습니다.

public ParcelFileDescriptor openDownloadedFile (long id)
파일 처리를 위해 다운로드한 파일을 엽니다. 인자로 다운로드 항목의 고유ID를 넘겨줍니다.


DownloadManager.Request

DownloadManager에 다운로드 요청을 하기 위해 필요한 정보를 포함합니다. 다운로드할 파일의 주소(URI), 파일 저장 경로, 다운로드 항목의 제목 및 설명을 설정할 수 있습니다. DownloadManager.Request의 주요 메서드는 다음과 같습니다.

API
public DownloadManager.Request (Uri uri)
DownloadManager.Request의 생성자입니다. 인자로 다운로드할 파일의 URI를 지정합니다. HTTP 형식만 지원합니다.

public DownloadManager.Request setAllowedNetworkTypes (int flags)
다운로드 진행시 사용 가능한 네트워크 종류를 설정합니다. 모바일 네트워크(3G)와 Wi-Fi 중 하나를 선택할 수 있습니다. 대용량 파일 다운로드시 실수로 3G 네트워크를 사용하여 데이터를 다운로드하여 많은 요금이 부과되는 것을 방지하기 위한 목적으로 사용할 수 있습니다. 사용 가능한 네트워크를 명시적으로 지정하지 않으면 모든 네트워크에서 다운로드를 수행할 수 있습니다.

public DownloadManager.Request setTitle (CharSequence title)
다운로드 항목에 표시될 제목을 지정합니다.

public DownloadManager.Request setDescription (CharSequence description)
다운로드 항목에 표시될 세부 설명을 지정합니다.

public DownloadManager.Request setDestinationUri (Uri uri)
다운로드할 파일이 저장될 경로를 지정합니다. 외부 미디어(예:SD카드)의 경로여야 하며, 외부 미디어에 데이터를 쓰기 위해 WRITE_EXTERNAL_STORAGE 권한을 지정해야 합니다.


DownloadManager.Query

다운로드 항목에서 원하는 정보만을 조회하기 위한 필터를 설정합니다.

API
public DownloadManager.Query ()
모든 다운로드 항목을 조회하는 객체를 생성합니다.

public DownloadManager.Query setFilterById (long... ids)
지정된 id에 해당하는 다운로드 항목만을 조회하기 위한 필터를 설정합니다.

public DownloadManager.Query setFilterByStatus (int flags)
특정 다운로드 상태의 다운로드 항목을 조회하기 위한 필터를 설정합니다.

DownloadManager를 사용하는 예제를 통해 DownloadManager 클래스를 사용하는 방법에 대해 자세히 알아보겠습니다.

[어플리케이션 정보]

액티비티
  • Main (Main.java)

레이아웃
  • main.xml

권한 (uses-permission)
  • android.permission.INTERNET
  • android.permission.WRITE_EXTERNAL_STORAGE

API Level
  • 9 (Android 2.3)
예제 코드 :

예제 애플리케이션에서는 다운로드할 파일의 주소를 입력받아 해당 파일을 다운로드하는 기능과 마지막으로 다운로드를 요청한 파일의 다운로드를 취소하는 기능, 다운로드한 항목을 조회하는 기능을 제공합니다. 예제 애플리케이션의 완성된 모습은 다음과 같습니다. EditText에 다운로드할 파일의 URL을 입력하도록 되어있으며, 각 버튼을 눌러 필요한 작업을 수행할 수 있습니다.




예제 애플리케이션의 레이아웃을 다음과 같이 작성합니다.

[main.xml]
01.<?xml version="1.0" encoding="utf-8"?>
02.<LinearLayout
04.android:orientation="vertical"
05.android:layout_width="fill_parent"
06.android:layout_height="fill_parent">
07.
08.<EditText
09.android:layout_height="wrap_content"
10.android:layout_width="fill_parent"
11.android:hint="Enter URL"
12.android:id="@+id/downloadUrl"
13.android:inputType="textUri" />
14.<Button
15.android:layout_width="wrap_content"
16.android:layout_height="wrap_content"
17.android:id="@+id/addQueueButton"
18.android:text="Add to download queue" />
19.<Button
20.android:layout_width="wrap_content"
21.android:layout_height="wrap_content"
22.android:text="Cancel latest download"
23.android:id="@+id/cancelDownloadButton" />
24.<Button
25.android:layout_width="wrap_content"
26.android:layout_height="wrap_content"
27.android:text="View downloads"
28.android:id="@+id/viewDownloadsButton" />
29.
30.</LinearLayout>

다음, 액티비티 코드를 작성합니다. 위젯 인스턴스 및 DownloadManager, DownloadManager.Request, Uri의 인스턴스를 선언합니다.

[Main.java]
01.public class Main extends Activity implements OnClickListener{
02.private EditText downloadUrl;
03.private Button addToQueueButton;
04.private Button cancelLatestButton;
05.private Button viewDownloadsButton;
06.
07.private long latestId = -1;
08.
09.private DownloadManager downloadManager;
10.private DownloadManager.Request request;
11.private Uri urlToDownload;

다음, 다운로드가 완료를 알려줄 브로드캐스트 리시버를 생성합니다. DownloadManager는 다운로드가 완료되었을 때 DownloadManager.ACTION_DOWNLOAD_COMPLETE 를 액션으로 갖는 브로드캐스트 메시지를 보내며, 이를 처리하는 브로드캐스트 리시버를 선언하면 특정 항목이 모두 다운로드 되었을 때 수행할 동작을 구현할 수 있습니다.

1.private BroadcastReceiver completeReceiver = new BroadcastReceiver(){
2.
3.@Override
4.public void onReceive(Context context, Intent intent) {
5.Toast.makeText(context, "다운로드가 완료되었습니다.",Toast.LENGTH_SHORT).show();
6.}
7.
8.};

이제 액티비티 코드를 구현하겠습니다. onCreate() 에서 다음과 같이 각 인스턴스의 객체를 받고, 버튼의 리스너를 등록하는 작업을 수행합니다.

01.@Override
02.public void onCreate(Bundle savedInstanceState) {
03.super.onCreate(savedInstanceState);
04.setContentView(R.layout.main);
05.
06.downloadUrl = (EditText)findViewById(R.id.downloadUrl);
07.addToQueueButton = (Button)findViewById(R.id.addQueueButton);
08.cancelLatestButton = (Button)findViewById(R.id.cancelDownloadButton);
09.viewDownloadsButton = (Button)findViewById(R.id.viewDownloadsButton);
10.
11.downloadManager = (DownloadManager)getSystemService(Context.DOWNLOAD_SERVICE);
12.
13.addToQueueButton.setOnClickListener(this);
14.cancelLatestButton.setOnClickListener(this);
15.viewDownloadsButton.setOnClickListener(this);
16.}

다음, onPause()에서 다운로드 완료시 발송되는 브로드캐스트 메시지를 처리하는 브로드캐스트 리시버를 등록합니다.

1.@Override
2.public void onResume(){
3.super.onResume();
4.IntentFilter completeFilter = new IntentFilter(DownloadManager.ACTION_DOWNLOAD_COMPLETE);
5.registerReceiver(completeReceiver, completeFilter);
6.}

이제 각 버튼을 눌렀을때 처리할 작업을 구현할 차례입니다. onClick() 메서드에서 각 버튼에서 수행할 작업을 구현합니다. 다운로드 버튼을 누르면 EditText에 입력한 URL을 가져와 DownloadManager.Request를 생성한 후, 제목과 설명, 그리고 다운로드한 파일을 저장할 경로를 지정한 후에 DownloadManager에 다운로드를 요청합니다. 예제에서는 외장 메모리(SD카드)에 저장하도록 구현하였습니다.

예제와 같이 외장 메모리의 공용 다운로드 영역에 데이터를 저장하려면 데이터 저장 전에 해당 디렉터리가 생성되어 있는지 필히 확인해야 하며, 이를 위해 mkdirs() 메서드를 사용하여 디렉토리가 존재하지 않을 경우 디렉토리를 생성하도록 구현합니다.

다운로드 취소 버튼을 누르면 마지막으로 요청한 다운로드를 취소하며, View Downloads 버튼을 누르면 다운로드 현황을 보여주는 액티비티를 표시하도록 구현하였습니다.

01.@Override
02.public void onClick(View v) {
03.switch(v.getId()){
04.case R.id.addQueueButton:
05.urlToDownload = Uri.parse(downloadUrl.getText().toString());
06.List<String> pathSegments = urlToDownload.getPathSegments();
07.request = new DownloadManager.Request(urlToDownload);
08.request.setTitle("다운로드 예제");
09.request.setDescription("항목 설명");
10.request.setDestinationInExternalPublicDir(Environment.DIRECTORY_DOWNLOADS, pathSegments.get(pathSegments.size()-1));
11.Environment.getExternalStoragePublicDirectory(Environment.DIRECTORY_DOWNLOADS).mkdirs();
12.latestId = downloadManager.enqueue(request);
13.downloadUrl.setText("");
14.break;
15.
16.case R.id.cancelDownloadButton:
17.downloadManager.remove(latestId);
18.break;
19.
20.case R.id.viewDownloadsButton:
21.startActivity(new Intent(DownloadManager.ACTION_VIEW_DOWNLOADS));
22.break;
23.}
24.}

마지막으로, 액티비티가 비활성화 될 때 다운로드 완료를 감지하는 브로드캐스트 리시버를 해제합니다.

1.@Override
2.public void onPause(){
3.super.onPause();
4.unregisterReceiver(completeReceiver);
5.}

애플리케이션을 실행해 파일을 다운로드 해보도록 하겠습니다. 예제에서는 안드로이드 SDK (Starter Package)를 다운로드합니다. EditText에 다운로드할 파일의 URL을 입력한 후 'Add to download queue' 버튼을 누르면 잠시 후 다운로드가 시작되고, 알림 바에 다운로드 현황이 표시됩니다.





다운로드할 파일의 경로를 입력합니다.




파일 다운로드가 진행되는 모습

다운로드가 완료되면 다음과 같이 다운로드 완료 메시지가 표시됩니다.





다운로드가 완료 메시지가 표시됩니다.


View download 버튼을 누르면 다운로드한 항목을 조회하는 액티비티가 표시되며, 다운로드한 항목에 대한 정보를 조회하거나 적합한 애플리케이션이 존재할 경우 다운로드한 파일을 실행할 수 있습니다.





다운로드한 항목들의 정보를 조회할 수 있습니다.


이것으로 DownloadManager를 통해 파일을 다운로드하는 방법에 대해 간단히 알아보았습니다. 예제에서 사용한 코드와 API를 참조한다면 실제 애플리케이션에서 DownloadManager를 사용하여 파일을 다운로드하는 것 또한 어렵지 않게 구현할 수 있을 것입니다.




=================================

=================================

=================================







반응형


관련글 더보기

댓글 영역
